Parametric Fluted Door | Shutter Panel – Revit Carpentry Family

$19.99 $35.00

This Revit family is a fully parametric fluted carpentry panel featuring a clean dual-zone design - a smooth solid panel combined with a vertically fluted lower section. Designed for premium joinery applications, this family is ideal for wardrobe shutters, cabinet doors, wall panels, and custom carpentry.

Built with clean constraints and lightweight geometry, it allows designers to control proportions, fluting intensity, and materials effortlessly while maintaining BIM accuracy.

This Revit family is a fully parametric fluted carpentry panel featuring a clean dual-zone design - a smooth solid panel combined with a vertically fluted lower section. Designed for premium joinery applications, this family is ideal for wardrobe shutters, cabinet doors, wall panels, and custom carpentry.

Built with clean constraints and lightweight geometry, it allows designers to control proportions, fluting intensity, and materials effortlessly while maintaining BIM accuracy.

WHAT’S INCLUDED

1 Revit Family File (.RFA)

1 High-Resolution Preview Image (JPG)

KEY FEATURES

Fully Parametric Controls

Easily adjust:

  • Overall panel width

  • Overall panel height

  • Panel thickness

  • Fluted zone height

  • Solid (plain) zone height

  • Flute width

  • Flute depth

  • Flute spacing / count

  • Edge margins

  • Material parameters (solid & fluted zones)

Dual-Zone Design Logic

  • Clean flat panel on top

  • Vertical fluting below

  • Proportions adjustable without re-modeling

  • Ideal for contemporary & luxury interiors

Lightweight & BIM-Optimized

  • Clean reference planes & constraints

  • No heavy nested arrays

  • Fast performance even in large projects

  • Works perfectly in plan, elevation, section & 3D

Render-Ready

  • Default wood material applied

  • Easily replace with veneer, laminate, MDF, PU paint, or fluted stone finishes
